LD-A Model Single Beam Motor Crane is designed basing on LD type crane which has more reasonable structure and lighter in weight.
This crane belongs to light duty crane, can be used with CD1 and MD1 hoist. Lift capacity is from 1 ton to 10 tons, spam from 7.5m to 22.5m, working condition is A3, working temperature is -25°C to +40°C.
It is mainly consists of girder, lifting mechanism, traveling mechanism and electrical equipment.
Controlling can be ground operation or operating room, the operating room divided into close one and open one, it can be installed at the left or right side up according to the practical situation. Direction of entering the operating room has two forms, sideway and ends in order to satisfy the users’ choice under different conditions.
This type crane is widely used in factory, store house and cargo yard, forbid to be used in corrosive and explosive places.

Sketch:
